Crown International RP3C Tube Electronics package.

The RP3C modules are used with Crown International's tape machines. This one matches the description for the type that was used with the 800 series decks. This unit is untested, and being sold as is.
Manufacturer: Crown
Call for pricing
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

This electronics chassis is a Crown Model RP3C, (Crown Schematic MI-118-b) and was used with the 800 series of Crown International Tape machines.

This version of the RP3C has a single input stage, with the meter in the center of the front panel.  The XLR is wired to an input transformer that sits directly behind the XLR jack.  There is an octal dummy plug above the XLR that can be wired for one of 3 input impedances using the internal transformer; 250Ω, 50Ω and Hi-Z.  Inserting a plug into the LINE input jack will bypass the balanced input circuit.

The RP3C is powered from a  deck assembly through a harness terminated in an octal plug.

Crown RP3C: single input stage, with selectable XLR mic level or 1/4” Line inputs on rear of the chassis, along with the Mic/Line slide switch.   Please feel free to call with any questions, Thanks!
