Digitech Studio Quad V2 4x4 Multi-Effects Processor

FEATURES

• Four independent 1/4” Inputs and Outputs
• 4 Effects at once
• 24 bit data path
• 180(Factory) 100(User) Programs
• Effects include: Reverbs, Choruses, Flangers, Auto-Panners, Tremolo, Intelligent Pitch Shifting, Delays (Analog and Digital), Rotary Speaker Simulator, Compressor, and Noise Gate.

SPECIFICATIONS

A/D Converter: 18 bit 128 x oversampled delta-sigma stereo
D/A Converter: 20 bit 64 x oversampled
Sampling Frequency: 44.1 kHz
DSP Section:
Static-Dynamic Instruction Set computer(S-DISC®)
Digital Signal Path Width: 24 bits (144.5 dB)
Internal Data Path Width: 48 bits (289 dB)
Dynamic Delay Memory: 64k x 24 bits (1.4 seconds)
Static Delay Memory: 256 24-bit registers (5.8 milliseconds)
Data ALU Processing: 11.3 MIPS
Address ALU Processing: 16.9 MIPS
Multiplier Size: 24 bits x 24 bits
Input Section:
Connectors: 4- 1/4" TRS Plug balanced
Nominal Level: -10 dBV, +4 dBu, software variable
Maximum Level: +18 dBu
Impedance: 10 k½
Output Section:
Connectors: 4- 1/4" TRS Plug balanced
Nominal Level: -10dBV, +4 dBu switchable
Maximum Level: +18 dBu
Impedance: 470 ½
General:
Frequency Response: 20 Hz. - 20kHz. ±3 dB
S/N ratio: Greater than 91 dB; ref =max signal, 22 kHz measurement bandwidth, unweighted
96dB Max signal “A” Unweighted
Total Harmonic Distortion Less than 0.03% (1 kHz)
Midi In, Out/Thru
Memory Capacity:
Factory: 191 Programs
User: 100 Programs
Power Requirements:
US and Canada: 120 VAC, 60 Hz
Japan: 100 VAC, 50/60 Hz
Europe: 230 VAC, 50 Hz
UK: 240 VAC, 50 Hz
Power Consumption: 30 watts
